Details Make the Difference
Ophthalmic / Vision Screener V100

Vision Screener V100

Protecting vision by detecting abnormality

hand held auto refractometer


Vision Screener V100


The Cell vision screener V100 is a hand held auto refractometer designed for clinicians to quickly detect vision abnormalities on patients from 6-month old to adults. The vision screening machine can screen both eyes at once from a distance of 1 meter. Once the pupils are in focus, the device will start to calculate automatically and deliver results within 1 second. The touch screen allows users to operate conveniently like using a smartphone. Rapid detection of the vision screening machine can effectively reduce the pressure of patients and shorten the examination time, clinicians can easily scan children or uncooperative patients.

Features

As a portable hand held auto refractometer, as well as the children auto refractometer, vision screener V100 can meet the detection of different age groups, and make the examination process more simple and convenient. Find a vision screener that satisfies your must-haves.


◉ Wireless data transfer by wifi
◉ Quickly deliver testing results in 1 second
◉ Interesting sounds to attract children
◉ Automated screening provides thorough, objective, and easyto-understand results
◉ Super user-friendly with minimal user
◉ training required
◉ Flip screen facilitate convenient vision measuring
◉ Capable of dealing with mass screening events


Quick Detection

• Myopia (nearsightedness)
• Anisometropia (unequal refractive power)
• Hyperopia (farsightedness)
• Strabismus (eye misalignment)
• Astigmatism (blurred vision)
• Anisocoria (unequal pupil size)

Patient Management Software


Mediview is the patient management system to help clinicians manage patient records and images and data collected by devices develop by Mediworks. The testing result delivered by V100 can be quickly transferred to Mediworks via a wifi connection.


Print Report Example


Clinicians can connect WiFi and Bluetooth to print out the test results after using the vision screening machine to detect the eye conditions of patients. Easy to operate, instant printing.


Specification

Measuring ModeBinocular/Monocular
Measuring Time1s
Automated Distance Sensing100cm±5cm
SPHRange:-9D~+7D
Range:0D~3D
CYL
Resolution:0.25D/0.01DResolution:0.25D/0.01D
Accuracy:±0.5DAccuracy:±0.5D
AxisRange:0~180°
Resolution:1°
Accuracy:±5°
Pupil SizeRange:4.0~9.0mm
Accuracy:±0.1mm
Pupil DistanceRange:30~80mm
Accuracy:±1mm
Fixation TargetSound and flashing light
Working Time5 hours
Data TransferWIFI
Screen4.3” full LCD touch screen
Charging PortUSB
Power Supply18650 Li-lion battery×2 , Voltage:3.7V , Current≥ 3400mAh
Targeted Patientfrom 6-months infant to adults
Weight800g
Power AdaptorPower Supply:~100-240V,50/60Hz,35VA Output:5V,2A
